PDA

TS-901


Android PDA POS Terminal

Android 7.0 os & Quad-core CPU

3.5‘‘ Touch Screen & IP64 (1.5M drop resistance)

4G/3G/2G/Bluetooth/WIFI connecting

RFID reader (LF, HF, UHF)

1D/2D Scanner

  • TS-901 PDA Specification





    Parameters

    Describe

    CPU

    MTK6737 1.2GHZ Quad-core

    OS

    Android 7.0

    Memory

    2GB+16GB(optional 3GB+32GB)

    LCD

    3.5’LCD,320*480TFT

    Touch Panel

    Capacitive Touch Panel

    Communication

    WIFI,GPS,Bluetooth,4G/WCDMA/EDGE/GSM,USB,UART

    External input

    27 full keyboard input, audio input

    Output

    Stereo speaker output,video playback

    SD/TF

    Max 128GB

    Standby Current

    Less than 5mAh

    Working current

    180mAh

    Battery capacity

    3400mAH

    Battery voltage

    3.6V~4.2V

    Stand-by time

    Over 600 hour

    Working hours

    Over 8 hour

    Cell voltage

    AC 100–240V,50/60Hz

    Charging current

    1000mA

    End-use temperature

    -15℃~65℃

    Stroage temperature

    -20℃~80℃

    Dimension

    175(L)*66(W)*30(H)mm

    Weight

    About 230g

    The extensible function



    HF

    13.56MHz

    ISO14443A/ISO14443B/ISO15693

    Read-write distance

    0~6cm

    Working current

    Less than 90mAh



    LF

    125KHz

    Uem4100

    Read-write distance

    0~15cm

    Working current

    60mAh



    LF

    134.2KHz

    ISO 11784/11785

    Read-write distance

    0~15cm

    Working current

    80mAh



    1D Barcode

    Terminal brand

    Symbol SE965/Honeywell N4300



    Bar code type

    UPC/EAN,Code 128,Code 39,Code 93,Code 11,Interleaved 2 of 5,Discrete 2 of 5,hinese 2 of 5,Codabar,MSI,RSS,Data Options,Serial Interface,Event Reporting

    Working current

    50mA

    2D Barcode

    Terminal brand

    Symbol SE4750---soft decode

    Bar code type

    Code39,PDF417,Data Matrix

    Working current

    450mA

    Camera

    5.0 Million Pixels

    Take a picture  Camera shooting
